SOUSHINE delivers high-performance Membrane Switches that combine sleek design, rugged durability, and exceptional reliability. Perfect for control interfaces in medical, industrial, and consumer applications, our switches offer a sealed, easy-to-clean surface that protects internal electronics from moisture, dust, and chemicals. We engineer user interfaces that are not only functional and long-lasting but also enhance the aesthetic and user experience of your final product.
What is a Membrane Switch?
A membrane switch is a user interface constructed from multiple layers of flexible polymer films and adhesives. The top layer, known as the graphic overlay, is the visual interface for the user, printed with keys, symbols, and branding. Sandwiched beneath are conductive circuit layers. When a user presses a key on the overlay, it flexes a top circuit layer through a spacer gap to make contact with a bottom circuit layer, momentarily closing a circuit and registering the command. They can be tactile (with a “click” feedback) or non-tactile.
How does it work?
The operation of a membrane switch is elegant in its simplicity. It consists of several key layers:
- Graphic Overlay: The protective, decorative outer layer the user interacts with.
- Top Circuit Layer: A thin, flexible film with conductive traces printed on its underside.
- Spacer Layer: An adhesive layer with cutouts that creates a gap, keeping the circuits normally open.
- Bottom Circuit Layer: A stationary film with the other half of the circuit traces. When a key is pressed, the top circuit layer is pushed through the spacer’s cutout, touching the bottom circuit layer at a specific point. This completes the circuit. The processor in the device detects which circuit was closed and executes the corresponding function. Releasing the key allows the top layer to flex back, opening the circuit again.
How We’ve Changed: From Simple to Sophisticated Interfaces
At SOUSHINE, we have evolved from manufacturing basic membrane keypads to engineering fully integrated and sophisticated interfaces. The old approach focused on producing functional but standard switches. Now, SOUSHINE integrates advanced features directly into our designs. This includes embedding LEDs for backlighting, incorporating EMI/RFI shielding for electrical protection, and designing for superior tactile feedback. Our change is about creating smarter, more resilient, and more user-friendly interfaces.
Key Application Areas
Why Choose SOUSHINE?
When you partner with SOUSHINE, you are investing in a superior user interface. Building on our extensive experience, we now offer advanced solutions that provide a distinct competitive advantage:
- Unmatched Durability: Our switches are completely sealed and resistant to environmental hazards, making them ideal for demanding applications.
- Complete Design Freedom: We offer limitless customization for graphics, colors, shapes, and backlighting to perfectly match your brand identity.
- Low-Profile & Easy Integration: The thin, flexible nature of our switches allows for sleek product designs and simple mounting.
- Cost-Effectiveness: We deliver a highly reliable and customized interface at a lower total cost than traditional mechanical switch assemblies. Elevate your product’s design and functionality with SOUSHINE.
